Last week I had the privledge of presenting a session at The Springone 08 Conference in Antwerp, Belgium. Here is the slide deck for the presentation.

Technorati Profile tags: ria appcelerator soa architecture springone08

This evening I will present a session to The Usability Professionals Association. Here is the slide deck for the presentation.

Technorati Profile tags: ria appcelerator soa architecture upa

This evening I was privileged to present a 2 hour session on architecture to a UGA Terry College of business master’s Systems and Analysis Design class taught by Jeff Howells. Here is the slide deck from the presentation.

Technorati Profile tags: ria appcelerator soa architecture ugaterrycollege

Purpose

The Appcelerator framework allows for the extension of the build and deployment process so that you can add components and modify the behavior of your service implementations. It is quite powerful and not only restricted to services, plugins for example could span across to the modification of applications and the entire build and deployment process for that matter. For simplicity, this article will identify how to create a new component added to our java service for monitoring performance.

Install Appcelerator

I’ve assumed that you’ve successfully downloaded and installed Appcelerator from http://www.appcelerator.org/products. Once you’ve gone through the installer you can get the java service

  app install:service java

You may want to get an existing plugin (I needed the java:spring plugin to implement my plugin):

  app install:plugin java:spring

Plugin Creation

Lets assume that our plugin is going to be called java:perf, to create the plugin project:

  cd $HOME/workspace
  app create:plugin . java:perf

This will create a sub directory named java_perf, now you will want to create a proper license entry in your build.yml for example check out build.yml. You now have the opportunity to modify the entry points in your java_perf.rb. I personally wanted to setup my install script so that:

• dynamically builds the jar when we add the plugin to a project
• modified the spring.xml to include the bean entries for my component

All of this is in before_add_plugin(event) callback. If you want to see where this is called, check out add_plugin.rb. Once my coding is complete (added my source files to java_perf/src), I created the plugin distribution:

rake zip

Install the plugin

As you noticed, I haven’t covered debugging the plugin just yet, this is because i want to first set up the plugin for installation and then work with it in my install directory. Lets install it to my local machine:

app install:plugin java_perf.zip

Add the plugin to my project

I thought that I’d create a blank java project real quick

cd workspace
app create:project . myproject java

now we can add the spring plugin and our new java:perf plugin to our project

cd myproject
app add:plugin java:spring
app add:plugin java:perf

You can now directly modify the java_perf.rb file in your install directory

• windows: c:/Program Files/Appcelerator/releases/plugin/java_perf/1.0
• unix: /usr/local/Appcelerator/releases/plugin/java_perf/1.0
• mac os: /Library/Appcelerator/releases/plugin/java_perf/1.0

I suggest that you continue to modify the java_perf.rb this way to debug it and then finalize by copying back over to $HOME/workspace/java_perf

Next Steps

As a final parting you can release your new plugin so that others may be able to leverage it

cd $HOME/workspace/java_perf
app release java_perf.zip

-andrew

this article is cross posted at: http://www.appcelerant.com/implementing-an-appcelerator-plugin.html

Technorati Profile tags: ria appcelerator soa java plugin

New Site

Well after over 2 months of perfecting the message, Appcelerator announced the launching of their new developer network. What i really like about this is that they are eating their own dog food. Its slick stuff like this that makes me proud to be a part of the company. If you are thinking of using appcelerator or just want to see how to make a huge splash in the development community check out the site:

http://www.appcelerator.org

cheers

Technorati Profile tags: ria appcelerator soa

Purpose

If you are venturing to implement a Rich Internet Application (RIA) with Appcelerator, then there are features about the framework that I’m really geared up about that help you implement your solution effectively. When used together these items enable the agile creation of solutions in a shorter time that integrate nicely with services in an existing architecture and provide a richer user experience for clients.

Achieving Re-use

There are a bunch of ways to do this, personally I leverage app:content files judiciously. You can provide args in the definition of your content files so that you can use the same content file over again. Some things to keep in mind:

• reference the args as #{argname} in your element ids, any variables, and make sure that functions you call take this into account (possibly make them stateless)
• the order in which the content file is loaded to make sure that listeners are properly setup to respond to messages

here is an example app:content reference

<app:content lazy="false" on="mainstate[person] then show else hide"
  args="{'prefix':'person'}">
</app:content>

here is the content.html file

<div id="#{prefix}header" ...
</div>

I know that this may be abstract, but the point is that you can use the arg “prefix” to reuse the file and provide alternative behavior based on it.

Mocking Services

You can mock out server side services extremely easily with the framework. This is extremely useful whether your goal is:

• Visual Use Cases: implementing a prototype that results in 100% useable application code
• Working offline: no need to run a web server at all, you can directly run off of a simple file

Once you have this in place, you have a well defined contract in place which makes knocking out the service implementation a snap.

No restart

If you are just working on your application (no service work), you can directly make changes to your application without requiring rebuilding and redeploying your application. In java I typically work directly in my tomcat deploy directory and have an ant task to pull the web files into my workspace. With our next version of the framework coming out, this will be even easier with our support for Jetty coming and the Ruby based command line tool. In the meantime, the following is useful in your java project:

ant pullweb

Make sure that you have your deploy.dir setup in your $HOME/.ant.properties for example:

deploy.dir=/Applications/apache-tomcat-6.0.14/webapps

With our Ruby implementation for example, this is even easier (running webbrick directly in your workspace).

Great Support for Model Objects

I’ve touched a bit on this in a previous post on JSON serialization with Appcelerator java services. To summarize the framework enables

• Hibernate persistence: ModelObjects can easily be used with our Hibernate integration
• JSON serialization: Serializing and deserialing complex objects is a snap

Slick support for forms

In case you haven’t looked, you dont need to include a form tag anywhere in the application: simply add a fieldset attribute to your input elements and put something like this

<input name="age" fieldset="save_person" type="text"/>
<input name="name" fieldset="save_person" type="text"/>
<input value="Create Person" fieldset="save_person"/>
  on="click then r:create.person.request" type="button"/>

This will create a message of type r:create.person.request with the payload being all your input elements with fieldset of “save_person” ex:

{'name':'jim','age':'35'}

To me, this is very eloquent solution to leveraging form input elements with a messaging architecture.

Easy to use UI widgets

I love some of the widgets that are at your fingertips. Some of the ones that i use the most

• app:panel: slick styling
• app:datatable: great way to show rows of data
• app:chart: fantastic visual effects to bring life to data

All these widgets have a very terse usage that is very intuitive. For example, using this set, I was able to knock out a realtime dashboard application in 3 evenings.

Service Platform Options

Pitching the right framework is something that varies from project to project. For example, possibly your client wants to leverage an existing java infrastructure and is sold on its robustness for scaling enterprise applications, while on the other side possibly you want to take advantage of using a Rails controller and ORM/Active Record implementation for rapid development. On the same level you also have the option for implementing services to customers that deliver in a .Net solution architecture. Many other platforms also exist (python, PHP) enabling the opportunity to plug into those services as well.

The app:get non-visual widget also makes pre-existing services accessible as well and since Messaging is at the heart of the implementation, plugging into an ESB or pure MOM framework is perfectly setup as well.

Wrap Up

In this article 7 key tips have been covered

• re-use
• mock services
• no restart
• model objects
• messaging & forms
• UI widgets
• platform options

Although there are more items that have not been covered here, these are the ones that appeal personally to me and have noticed a huge gain in doing much more with less effort.

-andrew

This article cross posted at http://www.appcelerant.com/effectively-implementing-appcelerator-rias-and-services.html

Technorati Profile tags: ria appcelerator soa

Short snippet

Recently several people have asked me if i’ve seen Randy Pausch’s final lecture. its an extremely touching piece and i thought that i’d share it with anyone who hasn’t had the opportunity to catch it. its 70 minutes off of his site and was so popular that oprah did a piece where he gave a 10 minute version of it. Please go check it out:

http://www.youtube.com/watch?v=ji5_MqicxSo

Technorati Profile tags: randypausch cmu

a kickin gift

this year i received a subscription to c & h beer of the month club. this was probably one of the most excellent gifts i’ve received in quite some time. the low down:

• 12 bottles every month from 2-3 breweries (each brewery provides 3 bottles of a given type of beer)
• unique beers that i personally have never tried before
• this month: 2 ales and 2 much larger lagers

casco bay brewing company

this month a brewing company based out of maine provided some nice beers:

• winter old port ale
• riptide red ale

both of these beers rock. during the cold months, i’ve really gotten to appreciate the bitter beers with some funky additives (cherry and orange peel). i personally liked the winter port a bit more, but the red ale was pretty nice too.

the harpoon brewery

harpoon is based out of boston, which kind of makes since for the name

• harpoon munich dark

i’ve had harpoon before, but not this one. probably my favorite in the stack

santa fe brewing

from new mexico – to be honest i’ve never had a NM beer before

• nut brown ale

this was the lightest beer in the stack, which as you may have guessed isn’t my favorite in the bunch. it does, however, balance the lot on out.

recommendation

i’d recommend this to anyone out there who is a beer enthusiast. my subscription runs out in march and based on the track record so far, i must say that i will renew then.

cheers!

Technorati Profile tags: beer

Purpose

The ability to debug applications is critical when things go sideways on you. I understand that for some of the developers out there learning a new framework can be challenging. Appcelerator provides developers with the tool-set to drastically reduce the amount of javascript code that they need to write and to be honest I think that the more you use the framework, the less you will need to debug applications as you familiarize yourself with the syntax.

Alerts

Prior to logging, alerts were the best way to display state during execution (showing you how old school I’ve been). Nonetheless, sometimes this is just easier since it blocks execution until you confirm. Sometimes however, you want to display objects. Lets take for example the following

alert(myobject);

You make get an alert that shows:

Well that isn’t very useful. If you want a nice string representation, use the following

alert(Object.toJSON(myobject));

Now you’ll get a nice JSON representation.

Logging

Safari and Firefox both provide you with the ability to view logging in the console. For firefox, you need to install firebug. If you are a safari user, you can use webkit (from the Debug menu, click “Show Javascript Console”). Both of which make available a console that displays log statements.

In firefox you can do the following in javascript

console.log("wassup");

I suggest however that you dont do that! Instead make use of the abstracted Logger

Logger.info("wassup");

This will not only show up in Firefox, but also in Safari’s console.

On another note, you can use the debug=1 parameter in your URL and you will see a ton of appcelerator messages (ex: http:localhos:8080/myapp?debug=1). I will caution you that it will almost look like spam given the amount of detail that is logged, but nonetheless its there if you want it.

You can also expand the Get and Post statements in firefox which will let you know what you have sent in your request and the JSON result that was returned from the server.

In-line Debugging

Lets say that you have an error in your app:script. Well in Firefox, you can take a look at the console and that will give you some pretty good feedback, however its going to be some cryptic text and you can’t step through it. You have 2 options that will enable you to step through the code:

• can make a call to a javascript function from your app:script (I normally define a project specific javascript file and put my functions in it)
• define a $MQL in your javascript file – app:script goes away

Here is scenario 1:

<app:script on="r:someevent.response then execute">
  Myapp.dosomething(this.data);
</app:script>

and the corresponding javascript

Myapp = Class.create();
Myapp.dosomething = function(data)
{
  //code here
}

For scenario 2: alternatively you could just define in your javascript file

$MQL('r:someevent.response',function(type,msg,datatype,from)
{
    //code here
});

The downside of this is that your implementation is not colocated in a single html file, but the upside is that you can debug it. Note that if you are not using content files, then you could alternatively define the above in a script element instead (a little cleaner), however if its a large app, then you really will want to decompose your app and use content files.

IE Specific Debugging

To be honest I’m not a huge IE fan, but it makes up an install base of 80% of the market. Chances are that pretty much everyone out there is using IE if you are building an application that appeals to the general public. To this end, Microsoft has made the .Net Developer Studio available for debugging your applications. The steps are pretty simple:

• install .Net Studio and create a project
• add your javascript files to your project
• start IE with your app’s url
• in Visual studio, select debug process and select your iexplorer.exe (sometimes it wont attach, but just keep trying and you should get there eventually)

For understanding styling, I suggest downloading the Internet Explorer Developer Toolbar. This will allow you to inspect individual elements (using the hover) and then setting styling attributes on your elements. This is much better than changing your html and reloading your page, especially for large applications.

Firefox (Firebug) Specific debugging

As with IE, you can use the firefox plugin to step through your code.

• load your app
• open firebug
• click script and select the html or javascript file and set your breakpoints

As with IE, using the Inspect module in firebug is very useful for styling your application.

Wrap Up

In this article we covered a bunch of ways that you can get down to the details in your application

• alerts (and displaying objects as strings)
• logging (appcelerator debug mode, custom log statements, ajax payloads)
• in line javascript debugging and styling

For many this may be an obvious repeat of the mechanisms that they currently use as web developers, but hopefully it will uncover some of the tactics that are used. This article has been cross posted at: http://www.appcelerant.com/debugging-appcelerator-applications.html

Technorati Profile tags: debugging tags: javascript appcelerator ria ajax

Purpose

Once you have developed a functional application and are priming for a roll-out, it will be in your interested to tune your application and identify those touchpoints which are candidates for tuning. I’ve preferred taking a quantitative approach to performance tuning so that you can compare metrics before and afterwards to identify improvement from a measurable perspective. To this end, it is possible to record statistics both client and server side (currently only for java services). Sometimes the culprit may be server side or client side and determining the area where performance bottlenecks exist is important which is why taking on a triangulation approach is important.

Client Side

Currently in the client the client, you can invoke the Appcelerator.Util.Performance component. To enable it, simply include logStats=1 in your url, for example: http://localhost:8080/myapp?logStats=1. The performance component by design will have no impact on your application unless you include this parameter. By default, the servicebroker will calculate the statistics for handling all message types both local and remote. The statistics will include the following:

• last – the last recorded time
• mean
• hits – aka count
• min
• max
• total – total time overall

These statistics will be logged to the console (available in Firefox with Firebug and in Safari with Webkit). However, you do not need to have logging available to inspect the statistics (please see the section “Viewing Client Side statistics” below). In addition the component also allows for resetting all statistics to restart your recording.

Capturing your own statistics

If for some reason you want to capture statistics at a finer level, you can easily to this in javascript:

var stat = Appcelerator.Util.Performance.createStat();
//do some work
Appcelerator.Util.Performance.endStat(stat,"mystat","mycategory");

In this example we create a statistic called “mystat” that will be included in a category of “mycategory”. This is useful for filtering through your stats as well as being able to compare statistics side by side. For example, the service broker will automatically record the following categories:

• remote
• local

Viewing Client Side statistics

You may want to include the following content file in your application and make it visible when the logStats parameter is included.

Here is the clientperformance.html source.

Wrap Up

We covered in this article

• how you can capture statistics for client side applications
• some performance tips in regards to client applications

In a later article we will identify how you can take this a step further to capture statistics on the server side as well with java services.

this article is cross posted at http://www.appcelerant.com/performance-tuning-appclerator-applications.html

Technorati Profile tags: performance appcelerator javascript ria

upon the discussion of bad smells, a mechanism that does not support measurement is useless when calculating improvement. hence the need for statistics arises. to this end i’ve found that the art of decomposing performance is necessarily binded towards a scientific approach. again this is a teaser for a following post…. to come: how to properly tune appcelerator applications and back end services…....

-andrew

Technorati Profile tags: performance appcelerator

let me first start off by saying that i have an unique taste, so the mainstream may or may not agree. additionally, i have a certain appreciation for history, so take it for what its worth. lets get down to it

movies

• charlie wilsons war: saw it thrice in the theater and yes philip seymour hoffman tore it up
• departed: i used to hate leanardo di crapio (yes i called him decrapio), he was steller and mat daemon as you can tell knows the southie accent
• apocolypto: granted the mayans didn’t really encounter the conquestadores, but forget the ending, the movie was right on
• the aviator: howard hughes as real as it gets: “wave of the future”
• master and commander: didn’t like it as much the first time as the 2nd or the 22nd: solid

comedy

now for some comedy (putting on the headphones has never made me smile as much @ work)

• nick swardson: PARTY.
• sean rouse: HILLARIOUS (even if a little bit risky)
• christopher titus: love the batman
• daniel tosh: love it when the jokes only appeal to 2 out of 100
• david cross: never has someone from atlanta been so foul

gud stufff

Technorati Profile tags: comedy movies

i was recently presented that symbols are not a “proper” thing to include in blog posts. well, something about running your own blog is that you can say phuck it: symbols rule and i must say that they are == awesomeness. hence for those out there, i can do nothing but recommend them to you, forget google analytics, forget search indexing, consider your blog as an opportunity to put your personal stamp on your site, if you so wish. at the end of the day unless you have a huge audience this is your blog. personally, probably my mother reads my blog and thats it, so might as well write in the language that best suits you, so if that includes all lowercase and symbols, let the shizit fly bud. my props.

Technorati Profile tags: blogging

last week i headed to rio de janeiro with 3 buddies. its been 8 years since i headed down there, and it continues to bring nothing but raves (thats a euphemism btw). i love brazil, there is something about the place that i cant really put into words. when i retire someday, ill move there and grab a penthouse down in ipenima and you’ll never see another blog from me again. :) back in the standard work mode again and that feels good, but not nearly as good as it was down in copacabana.

Technorati Profile tags: rio carnival

last weekend i headed up to north carolina (or whereever kennesaw state is) to attend socon08. to be honest i headed into socon not really knowing what socon was completely. ended up that it really wasn’t quite as technical as i thought it was. which is….. completely awesome. in addition to technologists, i met quite a few individuals from angel investors to journalists, to real estate practitioners. its fair to say that the event was centered around the domain of social networks.

the attendee list was chuck full of entrepreneurs, and i saw a lot of faces that i recognized from atlanta startupweekend and barcamp atlanta. aside from knowing that i was in good company, an excellent keynote speech was delivered in addition to an interactive speech that turned into an audience discussion. what i liked about this was the following goal which was achieved:

• i learned something
• i shared something
• i networked

it was a most excellent conference and i recommend the next version to anyone with marbles to attend socon09.

-andrew

Technorati Profile tags: socon08 socon
